- Common plan sheet scales include: one inch equals ten feet (1″=10′), one inch equals 20 feet (1″=20″), one inch equals 30 feet (1″=30″), one inch equals 40 feet (1″=40′), one inch equals 50 feet (1″=50′), and one inch equals 60 feet (1″=60″). These also happen to be the scales for which a standard engineering scale can be used to measure a plan. There is one corresponding drawing scale for each edge of the engineering scale. - Source: Internet
- For example, if you are measuring something that is 50 feet long on a plan with a drawing scale of one inch equals 50 feet (1″=50′), your engineering scale would show the number 5. If you are measuring something that is 54 feet long on a plan with a drawing scale of one inch equals 50 (1″=50′), your engineering scale would measure that something at 4 minor ticks marks past the number 5. Since there are 10 minor tick marks between major tick marks, your scale measurement would be 5.4 which you would then multiply by 10 to get 54 feet. - Source: Internet
- Technical drawings can be very valuable sources of information if you know how to get the information from them. On the surface, the plans you are analyzing might seem like just lines and shapes on paper. You need to have the proper tool for reading those lines and shapes. This is where an engineering scale is valuable. - Source: Internet
- For example, if you measure a distance from a plan with a drawing scale of one inch equals 20 feet (1″=20′) and your measurement is ten inches, the actual distance would have to be calculated to be 200 feet. The 200 feet equals 10 times 20 feet (20 feet for every one inch of measurement using the standard ruler). Using an engineering scale would make things a lot easier and more efficient especially if you plan on taking many measurements at a time. - Source: Internet
- At the far left side of each edge you will normally see one of the following numbers: 10, 20, 30, 40, 50, or 60. These numbers tell you the drawing scale for which you can use that edge to measure something off of a plan. For example, the edge with the number 40 would be used to measure things on a plan with a drawing scale of one inch equals 40 feet (1″=40′). - Source: Internet
- Just like a standard ruler that is 12 inches long, a standard engineering scale (also 12 inches long) also has six edges used for measuring. A standard ruler usually has only two edges with which to measure. One edge of a standard ruler would be for measuring things in inches and the other edge might be for measuring things in a different unit such as centimeters. - Source: Internet
- On the edge with a 10 (for a standard engineering scale), there are 12 major tick marks labeled 1 through 12. This is similar to a standard ruler except that with the engineering scale, the space between each major tick mark would normally represent 10 feet instead of just one inch. The minor tick marks between the major tick marks would represent one foot. - Source: Internet
